experiment
specification
|
main model |
name |
power (kw) |
overall size (l*w*h)m |
remark |
| xlg2-600e(i) |
precise continuous scraping coating machine |
90kw | 23.0*2.2*2.68 |
baking tunnel length 18m，coating width 600mm |
| xlg2-600h(i) |
precise continuous scraping coating machine |
120kw | 29.0*2.2*2.68 |
baking tunnel length 18m，coating width 600mm |
features
1、new upper hopper design
2、simple adjustable knife operation
3、high speed and thin coating process
4、coating speed can be 15m/min more.
main technical indicators
1、single side dry thickness error: ≤±2.0μm, areal density error: ≤±1.5%
2、 double side dry thickness error: ≤±2.5μm, areal density error: ≤±1.5%
3、 coating alignment error: ≤±0.5mm
