power
specification
|
main model |
name |
power (kw) |
overall size (l*w*h)m |
remark |
|
xjy3-680n |
single side extrusion coating machine |
300/90 (steam heating) |
45.0*3.5*3.1 |
baking tunnel length 36m，coating width 680mm |
|
xjy3-680n(i) |
single side extrusion coating machine |
310/100 (steam heating) |
48.0*3.5*3.1 |
automatic roll exchanging, automatic thickness measurement system |
features
1、mitsubishi(japan) and edi(american) die heads are optional
2、patented huff and puff valve precise adjustment
3、automatic roll exchanging without waste
4、patented adjustable air nozzle
5、invention patent of stable pressure pipe
6、patented non-impact feeding valve
7、heating mode: electric heating, oil heating, steam heating and ptc
8、the edge of the electrode can be coated synchronously
technical indicators：
1、thickness/areal density error: thickness: ±1.5um, areal density: ±1.0%
