electrode manufacturing line

specification

introduction：

we are the first one making automatic electrode production line in china. achieved online detection and intelligent control of the whole production line through the optimal combination of four core new processes and equipments , including double side extrusion coating of micro pore substrate, closed-loop control of multistage calendaring , ultra speed slitting and high vacuum continuous baking.

this manufacturing line adopts the design concept of "a whole flow", effectively integrates the different sections equipments of the electrode manufacturing according to the standard production capacity, matches the capacity of single machine, adds the latter detecting sensor in advance, adopts the material intelligent temporary storage technology in structure, all processes data shared and intelligent decision, which improve the production efficiency and product consistency.

features：

1、coating, calendaring, slitting and baking in a continuous process, without interruption of winding and unwinding to ensure consistency;

2、use robot and agv connect to baking equipment, ensure automatic production and manufacturing efficiency improving;

3、whole process backtracking and optimization to achieve self-adaptation and intelligence which ensure the production stability.

composition

process

features and advantages

micropore substrate double side extrusion coating process and equipment

1.double side coating synchronously;

2.support next generation of microporous substrate

patent：zl201310570720.7

zl201410376056.7

zl201320455269.x

1、avoid winding twice and connect with calendaring;

2、reduce defects, high safety

3、slurry coating tightly, improve circulation life

closed-loop control multistage calendaring process and equipment

the closed loop control of calendaring density and extensibility, instead of open loop control of thickness

patent：zl201420526037.3

zl201410187567.4

zl201620906170.0

1、speed 60 m/min, can connect to the coating;

2、reaction rate increase 1.5 times

3、closed-loop control density with good consistency

4、without edge defects, high safety.

ultra speed slitting process and equipment

multiple knife cutting instead of vertical drawing fracture

patent：zl201410081231.x

1、independent traction, good process connection;

2、reduce burrs and eliminate short circuit danger.

high vacuum continuous baking process and equipment

heating evaporation , vacuum dewartering and cooling processes segment execution

patent：zl201310334061.7

zl201410291850.1

zl201420421293.6

zl201510112223.1

1、continuous working, increase efficiency by 50%;

2、flow production with good consistency

production line online detection and intelligent control

online detection system, real-time feedback control system,electrode manufacturing process database

patent：zl201620904797.2

zl201620904776.0

1、whole line online detection;

2、whole line intelligent control;

3、improve quality and reliability.
