3c
specification
|
main model |
name |
inner size (h*w*d)/mm |
overall size (h*w*l)/mm |
power (kw)
|
capacity (wah /day) |
remark |
|
xkx8-212a(ⅲ) |
intelligent vacuum oven |
330*830*1200*3 |
1990*1630*1885 |
15 |
6-8 |
|
features
1、heating: with internal/external heating sources and air flow cycle; internal cycle for heating, external cycle for temperature preservation,fast heating and good temperature uniformity;
2、vacuum degree: -0.08 to -0.1mpa;
3、plc control the valves
4、five channels safety protection for over-temperature control.
technical indicators
1、temperature uniformity: dry air condition: ±2 ℃
vacuum condition: ±3 ℃
2、air tightness: 24 hours leakage rate ≤2000pa
3、heating time: 1.5 hours
