products

  • aging oven
  • aging oven
  • aging oven
aging ovenaging ovenaging oven

specification

main model name cavity size(l*w*h)
overall size (l*w*h)
volume (m3)
power(kw) adaptive range remark
xhx8-120a/b aging oven 1800*900*1600
2100*1150*2350

2.59

7.2 aging, soft bag finished product finalization b type belt drying trolley
xhx8-122a/b
oven
1200*1200*1500
1650*1500*1800
2.16 7.2 aging, soft bag finished product finalization
b type belt drying trolley

mechanical characteristics


1、circular hot air circulation with left and right convection
2、double layer heat insulation.
3、the door is double sealed
4、stainless steel liner
5、one trolley can be put in each set, with a bearing capacity of more than 500kg


electrical characteristics


1、five ways of safety protection
2、three position temperature control, pid control, small thermal inertia, good temperature control effect.
3、upper limit over temperature alarm can be set
4、set baking temperature at will
5、multiple centralized control and shared control system.




xhx8-122a/b technical indicators

1、temperature uniformity: in dry gas state:±2℃
2、heating up time:45min
