specification
|
main model |
name |
power (kw) |
overall size (l*w*h)m |
remark |
|
xst3-700h(i) |
automatic double side transfer coating machine |
168 |
32.0*2.15*2.85 |
baking tunnel length 24m，coating width 700mm |
features：
1、non-impact constant speed coating patented technology
2、automatic dry and wet thickness closed loop control technology
3、four tension linkage control
4、electrode coating speed calibration function
5、arc shape transmission tunnel design
6、high precision front and back/ left and right automatic alignment
advantages to solve the below problems：
1、 solve electrode drawing (double side transfer coating historical problem)
no horizontal movement for instant gap: by patented skew roll
2、high speed coating
quick response: big displacement lever force saving
3、high precision method:
uniform slurry : double screw mixing feeding by automatic liquid level setting
knife adjustable: adjustable curvature combined knife
4、perfect head and tail control
tail: large break of material less accumulated material
head: big and small rolls bus rectify in time
technical indicators：
1、 single side dry thickness error: ≤±2.0μm, areal density error: ≤±1.5%
2、double side dry thickness error: ≤±2.5μm, areal density error: ≤±1.5%
3、coating length / trailing error: ≤±0.5mm
